What is a laser chiller and what does a laser chiller do?

Apr 19,2023 | TOPTEK

Laser chiller is a kind of water cooling equipment, which is mainly cooled by the circulation of the cooling water tank. It has the functions of constant temperature, constant pressure and constant flow. It is also called in the market: laser cooling water tank, cooling machine, constant temperature cooler, water cooling As the name implies, laser chiller It is to use the cooling capacity of the compressor to freeze the pure water in the water tank, and then bring the cooling water into the body of the laser machine gun to cool down the heating module. The temperature of the laser machine, laser gun and Q head, especially the Q head, is very high when it is working. If there is no water or no chiller, it may burn out the Q head after working for 3 seconds.

The laser chiller is also equipped with a water filter, which can filter the impurities in the circulating water, prevent the pipeline from being dirty and blocked, and make the operation of the laser equipment safer. The laser machine adopts Hitachi imported compressor, the cooling effect is efficient and stable, and it is equipped with a special control panel, which can make the control accuracy reach ±0.1°C. The control precision is small, and the laser machine is less affected by temperature. The more stable the efficiency, the finer the processed products! The laser chiller has a flow protection function. When the water flow rate is less than the set value, the compressor will automatically stop working to ensure safer use of laser equipment.

The laser chiller mainly cools the laser generator of the laser equipment through water circulation, controls the working temperature of the laser generator, and keeps the laser generator working normally for a long time. During the long-term operation of laser equipment, the laser generator will continuously generate high temperature. Excessive temperature will affect the normal operation of the laser generator. Therefore, a laser chiller is required for water circulation cooling and temperature control.

According to the type of laser generator and the classification method of chillers, laser chillers are divided into carbon dioxide glass laser tube laser chillers, carbon dioxide metal radio frequency tube laser chillers, semiconductor side pump laser chillers, semiconductor end pump laser chillers, YAG lasers Chiller, Fiber Laser Chiller, UV Laser Chiller.

It can be said that the use of the laser chiller can not only make the laser machine work safely and normally, but also ensure the safe use and service life of the laser machine, and more importantly, make the working efficiency and precision of the laser machine reach the best state , Create greater benefits for the enterprise!
